UNI-T UT705 Single Function Loop Process Calibrator

UNI-T UT705 Single Function Loop Process Calibrator in Sri Lanka

High-Accuracy mA Signal Calibrator for 4-20mA Loops

The UNI-T UT705 Single Function Loop Process Calibrator provides 0.02% accuracy for measuring/sourcing DC current (24mA), voltage (30V), and loop power (24V) – ideal for troubleshooting PLC/DCS systems, transmitters, and valves in Sri Lanka industrial automation.

Looking for unbeatable deals? Discover our UNI-T Loop Calibrator Price Comparison – specs, features & best rates in Sri Lanka!

Features step/ramp simulations (manual/auto), USB interface for data transfer, rechargeable battery with extended runtime, and intelligent auto-off function for efficient on-site loop testing and maintenance.

Key Features

Accuracy: ±(0.02% + 2 digits) for DCV (30V), DCI (24mA), loop current

Ranges: mA (0-24mA), VDC (0-30V), 24V loop power (±10%)

Outputs: DC current source/simulate, manual/auto step (25%/100%), ramp (slow/fast/25% step-ramp)

Connectivity: USB interface for PC connection and data logging

Power: 9V battery (6F22), LCD backlight (63×40mm), auto power-off

Build: 1m drop-proof, red/grey case, 96×193×47mm, 410g

Applications

4-20mA transmitter calibration and testing

Valve positioner and actuator testing

Process loop diagnostics and maintenance

Package Includes

1 x UNI-T UT705 Loop Calibrator main unit

Complete test cable set

Rechargeable battery pack

USB charging adapter

Protective carrying case

Downloads

📄 Download UNI-T UT705 Data Sheet
📄 Download UNI-T UT705 User Manual
