UNI-T UT501A Insulation Resistance Tester Megohmmeter: Precision Electrical Testing with Advanced Safety Features
UNI-T UT501A Insulation Resistance Tester Megohmmeter: Precision Electrical Testing with Advanced Safety Features
Regular price
Rs 24,950.00 LKR
Regular price
Sale price
Rs 24,950.00 LKR
Unit price
per
HOT LINE - 077 862 0567
The UNI-T UT501A Insulation Resistance Tester Megohmmeter, widely known as a Megger, is an advanced tool designed for the precise measurement of insulation resistance within various electrical systems. This sophisticated device is engineered to enhance safety, reliability, and efficiency in electrical testing, making it an essential instrument for electricians, technicians, and engineers. Featuring a robust suite of capabilities, the UT501A is certified by CE and UKCA, ensuring compliance with international safety and quality standards.
At the heart of the UT501A is its 2000 count LCD display, which provides clear and accurate readings. The device is equipped with an overload indication and backlight for ease of use in different environments. It supports AC voltage measurement and incorporates an auto power-off feature to conserve battery life. The auto discharge function ensures safety after tests by discharging residual electricity from the device under test.
The UT501A excels in continuous low resistance measurement and offers a continuous measurement mode, augmented by a red warning light and buzzer function for enhanced safety. It stands out with its ability to measure Polarization Index (PI) and Dielectric Absorption Ratio (DAR), coupled with automatic resistivity calculation. Additionally, its low resistance returning to zero function significantly improves accuracy, setting it apart from competitors.
Specifications and Features:
Test Voltages: 500V / 1000V / 2500V
Accuracy:
0MΩ~99.9MΩ Range ±(3%+5)
100MΩ~9.9GΩ Range ±(5%+5)
10GΩ~20GΩ Range ±(10%+5)
Short-circuit Current: <2mA
Low Resistance (Ω) Accuracy: 0.01Ω~200Ω (about 5.0V/>200mA）Range ±(2%+3)
AC Voltage (V): 30V~600V Range ±(2%+3)
Features: DAR, PI, Auto Range, Low Battery Indication, LCD Backlight, Light Alarm, Buzzer Alarm, High Voltage Indication, Overload Indication, Auto Discharge
With its comprehensive features and specifications, the UNI-T UT501A Insulation Resistance Tester Megohmmeter stands as a testament to UNI-T's commitment to quality, reliability, and safety in electrical testing equipment.
At the heart of the UT501A is its 2000 count LCD display, which provides clear and accurate readings. The device is equipped with an overload indication and backlight for ease of use in different environments. It supports AC voltage measurement and incorporates an auto power-off feature to conserve battery life. The auto discharge function ensures safety after tests by discharging residual electricity from the device under test.
The UT501A excels in continuous low resistance measurement and offers a continuous measurement mode, augmented by a red warning light and buzzer function for enhanced safety. It stands out with its ability to measure Polarization Index (PI) and Dielectric Absorption Ratio (DAR), coupled with automatic resistivity calculation. Additionally, its low resistance returning to zero function significantly improves accuracy, setting it apart from competitors.
Specifications and Features:
Test Voltages: 500V / 1000V / 2500V
Accuracy:
0MΩ~99.9MΩ Range ±(3%+5)
100MΩ~9.9GΩ Range ±(5%+5)
10GΩ~20GΩ Range ±(10%+5)
Short-circuit Current: <2mA
Low Resistance (Ω) Accuracy: 0.01Ω~200Ω (about 5.0V/>200mA）Range ±(2%+3)
AC Voltage (V): 30V~600V Range ±(2%+3)
Features: DAR, PI, Auto Range, Low Battery Indication, LCD Backlight, Light Alarm, Buzzer Alarm, High Voltage Indication, Overload Indication, Auto Discharge
With its comprehensive features and specifications, the UNI-T UT501A Insulation Resistance Tester Megohmmeter stands as a testament to UNI-T's commitment to quality, reliability, and safety in electrical testing equipment.
