UNI-T UDP6722 400V Single-Channel Switching DC Power Supply

UNI-T UDP6722 400V Single-Channel Switching DC Power Supply in Sri Lanka

Ultra High-Voltage Programmable DC Power Supply for Industrial Applications

The UNI-T UDP6722 400V Single-Channel Switching DC Power Supply provides extreme high-voltage output for advanced power electronics testing, industrial R&D, and specialized research applications. With programmable 0-400V DC capability and robust current delivery, it's perfect for high-voltage power semiconductor testing, electrostatic applications, and industrial power systems used across Sri Lanka's advanced manufacturing, research institutions, and engineering laboratories.

For the best deals, check our DC Power Supply Pricing across Sri Lanka!

Featuring a large color TFT touchscreen display, precision digital programming, comprehensive safety protection systems (OVP/OCP/OTP/Arc), and industrial interfaces (USB/LAN/RS232/GPIB), the UDP6720 delivers stable ultra-high voltage switching power with exceptional regulation. Its advanced automation capabilities make it ideal for production test systems, high-voltage component validation, and automated research applications.

Key Features

Ultra High-Voltage: 0-400V DC programmable output for extreme applications

High-Efficiency Switching: Low heat generation for continuous operation

Precision Programming: 1mV/1mA resolution for accurate control

Touchscreen Interface: 7-inch color TFT with graphical waveform display

Industrial Interfaces: USB/LAN/RS232/GPIB for system integration

Advanced Protection: Arc detection, OVP/OCP/OTP with safety interlock

Waveform Generation: Arbitrary waveform and pulse output capabilities

List Sequence Mode: Complex automated test sequences

Remote Sensing & Control: 4-wire sensing for accurate load regulation

Rackmount Design: 2U industrial chassis for system integration

Technical Specifications

Model

UNI-T UDP6722 400V Single-Channel Switching DC Power Supply

Output Channels

1 programmable ultra-high voltage output

Output Voltage Range

0–400V DC (high precision programming)

Output Current Range

0–20A (high-voltage optimized)

Regulation Type

Advanced high-voltage switching regulation

Display

7-inch color TFT touchscreen LCD

Load Regulation

≤0.02% + 10mV across full voltage range

Protection Features

OVP, OCP, OTP, OPP, arc detection, interlock

Interfaces

USB Device/Host, LAN, RS232, GPIB, Analog

Operating Modes

CV/CC, waveform, list sequence, trigger I/O

Operating Conditions

0°C to 40°C; industrial environment rated

Dimensions / Weight

2U rackmount; heavy-duty industrial construction

Industrial & Advanced Applications

Power Semiconductor Testing: IGBT/SiC/GaN device characterization

High-Voltage Component Test: Capacitor, insulator, and cable testing

Electrostatic Applications: Ionizers, electrostatic generators

Automated Production Lines: High-voltage burn-in and stress testing

Research Laboratories: Plasma physics, high-voltage experiments

Package Includes

1 x UNI-T UDP6722 400V Single-Channel Switching DC Power Supply

1 x High-Voltage Power Cord

1 x High-Voltage Safety Test Lead Set

1 x USB Communication Cable

1 x LAN Cable (CAT6)

1 x RS232 Cable

1 x GPIB Cable (optional)

1 x Rackmount Kit

1 x Quick Start Guide

User Manual

Downloads

📄 Download UNI-T UDP6722 Data Sheet
📄 Download UNI-T UDP6722 User Manual
